Frame

Phase 27´5 Custolite aluminium 6061, internal headset, specific 27´5 geometry, replaceable derailleur hanger, BSA bottom bracket.

Sizes

S: 395mm / M: 440mm / L: 480mm / XL: 520mm.

Rear shock

/

Shock setting

/

Fork

Suntour XCM RL 27´5 100mm, 30mm stanchions, 1-1/8” steering tube, 9mm QR axle. Settings: spring preload, remote hydraulic lock-out.

Headset

CH 9280, Internal ZS, 44mm external diameter cups.

Stem

MDK XC. Forged aluminium, +/-7º angle, 31.8mm barbore. Length size S: 75mm, 90mm M/L, 105mm XL.

Handelbar

MDK XC 0.2 Aluminium 6061 T6 double butted. 4.8mm rise, 680mm width, 9º backsweep, 0º upsweep, 31.8mm barbore.

Grips

Onoff Diamond, 130mm.

Seatpost

MDK XC. 6061 T6 forged aluminium. 27.2 diameter. 20mm setback. 350mm length .

Saddle

Exclusive Mondraker Phase 27’5 design.

Front brake

Tektro HDM285 hydraulic, 160mm 6-hole one-piece rotor.

Rear brake

Tektro HDM285 hydraulic, 160mm 6-hole one-piece rotor.

Brake lever

Tektro hydraulic brake, with 2 fingers lever.

Rim

MDK-XS1 27’5, 24mm external width, 32 spokes.

Spokes

Black stainless steel.

Front hub

MDK-XS1, 9mm QR axle, cup & cone ball bearings, IS 6 bolts.

Rear hub

MDK-XS1, 9mm QR axle, cup & cone ball bearings, IS 6 bolts, interchangeable freehub.

Front tyre

Vee Rubber 325 27’5 x 2.10 single compound, 30 TPI, Wire.

Rear tyre

Vee Rubber 325 27’5 x 2.10 single compound, 30 TPI, Wire.

Crank

Suntour XCM 3x9, 170mm length cranks in sizes S/M and 175mm in sizes L/XL.

Rings

40/30/22t all black, interchangeable design.

Bottom bracket

CH-46 Square.

Pedals

Wellgo LU-895N platform.

Chain

KMC Z100.

Front  derailleur

Shimano Acera FD-M3000, Top Swing, double pull, 3x9s.

Rear derailleur

Shimano Alivio RD-M4000 SGS, 9s.

Lever

Shimano Altus SL-M370, Rapidfire plus, 3x9s.

Sprocket

Shimano HG50 11-36T 9s.

Hanger

Mondraker M064.

Others

/

Weight without pedals

13.9kg.
